All-encompassing Expertise for Modern Door Systems

Contemporary hinged doors are not only functional elements, they also shape the architecture and create striking highlights while continuing to function as a secure, digital barrier. Roto Frank Window and Door Technology supplies a full range of components for these doors – from hinges, locks, and thresholds, to cylinders, lever handle sets, and state-of-the-art access solutions. The perfectly matched products from the Roto Door range form a fully integrated, complete system that marries design, operating convenience, and security for hinged doors. During the Fensterbau Frontale Trade Show in Nuremberg, Germany from March 24th to 27th 2026, Roto experts will be on hand in hall 1 at booths 303 and 304 to provide information about the Door product range.

Clear lines, large-scale formats, and individual expression bring modern architecture to life. With the Roto Solid C door hinge and turn restrictor, Roto allows for ultimate design freedom with high-quality concealed components. The turn restrictor’s damped end stop also reliably protects the door against being pulled open too far by limiting the opening width to a maximum of 125°, while all that remains visible is the slim, discreet rotating arm.

For striking highlights, the butt hinges from the Roto Solid B range offer an elegant appearance and precise adjustment, without forming gaps between the sash and frame hinge. The adjustment mechanisms are instead integrated into the hinge roller. Versions like the 218P and 318P, with a diameter of just 18 mm for vinyl doors, are available with trendy finishes such as jet-black matt or finely textured jet-black matt.

For spacious entrance areas and architecturally sophisticated projects, Roto Safe multipoint locks can be used to produce impressive doors from any frame material up to a sash rebate height of 9” 10’ (3,000 mm). The concealed mechanics and the operating lever on the side of the espagnolette also subtly blend into the door profile.

Aesthetically pleasing and easy to operate, the Roto Safe H650 lever-operated multipoint locking system is convenient and intuitive, simply by pulling up the door handle.

Also convenient and easy to use, the Roto Safe Tandeo automatic door locks without key operation, offering a retrofittable day-time release for added convenience. If the function is activated, the door can be opened from the outside without a key.

The Roto Safe Eneo CC electromechanical multipoint locking system opens and locks the main and additional locks using a motor and the 4in1 access control system. This system allows the door to be open either via a Bluetooth-connected mobile phone, a finger scan, an RFID-capable medium, or a numerical code.

Roto Door is also setting the benchmark when it comes to mechanical burglary inhibition. Multipoint locks from the Roto Safe range can achieve increased protection when paired with additional combination or Quadbolt locks.

A specific example is the Roto Safe C600 lock generation. It offers maximum flexibility for additional locks – from economical solutions to high-security features like the 17-point lock. This cylinder-operated multipoint locking system can be used to reliably secure doors of all material types up to a sash rebate height of 9” 10’ (3,000 mm). Additional features like the push-back safeguard after one key turn, and the optional drilling plate underline the elevated security options offered by this solution.

Roto’s electronic monitoring solutions complement the mechanical security options. For instance, Roto Safe deadbolt switch contacts, paired with contact elements from the Roto E-Tec Control MVS, offer reliable locking and opening monitoring for multipoint locks. The deadbolt switch contact is built into the frame component and is activated by the main deadbolt. When combined with the concealed MVS contact element, the status of the door is transmitted to alarm or smart home systems.

Deventer drop down seals also blend effortlessly into the design, as they are concealed in the hardware groove, creating a subtle appearance. Despite their minimal height, the drop down seals offer reliable protection against the elements. An integrated mechanism lowers the seal automatically, providing reliable sealing for the lower joint. The thresholds combine innovative hardware and sealing technology with sophisticated design, enabling a wide range of solutions for premium hinged doors made from vinyl or wood. The Roto Frame-Tec shims from the Roto Equipment range enable precise shimming and leveling of the thresholds. This ensures optimal load distribution and further increases the durability of the door systems.

Thanks to extensive system expertise, all components in the entire Roto product portfolio, including Roto Door, interact seamlessly with each other and offer the ideal solution for any requirement – the perfect match for door systems.
